Need a quote for ZXGD3006E6TA
Mobius holds none of this part in its own stock. Send the quantity you need and the Mobius team sources it for you.
Sell your excess ZXGD3006E6TA
Recover value for your excess stock by selling on Mobius. Painless quick process selling direct to other manufacturers with transparent fees.
Buying from Mobius
Inspection Report Included
We inspect all parts rigorously and will provide you with a report on request.
14 day Returns
Inspect parts for 14 days after purchase and return them if you find any issues.
Free Resale
Buy too much? We'll resell them on our site at no cost to you.
Read our FAQs or
Product Specifications for ZXGD3006E6TA
Type
Spec
Case/Package
LSSOP
Channel Type
Single
Continuous Drain Current (ID)
4 A
Element Configuration
Dual
Fall Time
35 ns
Height
1.4 mm
Height - Seated (Max)
1.4 mm
Length
3 mm
Manufacturer Package Identifier
SOT26 (SC74R)
Max Junction Temperature (Tj)
150 °C
Max Operating Temperature
150 °C
Max Output Current
10 A
Max Power Dissipation
1.1 W
Max Supply Voltage
40 V
Min Operating Temperature
-55 °C
Mount
Surface Mount
Nominal Supply Current
50 nA
Number of Channels
1
Number of Circuits
1
Number of Drivers
1
Number of Outputs
1
Number of Pins
6
Number of Terminals
6
Operating Supply Current
50 nA
Output Current
10 A
Power Dissipation
1.1 W
Radiation Hardening
No
REACH SVHC
Unaffected
Rise Time
48 ns
RoHS
Compliant
Schedule B
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
Terminal Pitch
950 µm
Width
1.6 mm
